5-20
PERFORMANCE DATA & PRESSURE CURVES
Revision Y05-01 Service Manual - WMZ
5.15.2 Heating.
Discharge Pressure VS.Outdoor Temp
10
12
14
16
18
20
22
24
26
-10 -5 0 5 10 15 20
Outdoor Temp.( WB
o
C )
Discharge Pressure(Bar[g])
25 DB (ºC)
20 DB (ºC)
15 DB (ºC)
Suction Pressure VS.Outdoor Temp
2.0
2.5
3.0
3.5
4.0
4.5
5.0
5.5
-10 -5 0 5 10 15 20
Outdoor Temp.( WB
o
C )
Suction Pressure(Bar[g])
15 DB (ºC)
20 DB (ºC)
25 DB (ºC)
