11
Seat Post Height Adjustment
The seat height can be adjusted as follows:
1. Remove the seat by pulling the seat swivel lever and lifting the seat off the seat post.
2. Unscrew the nut and bolt and remove from the tube. Try and avoid touching the top of the post as it has
serrations which could cut your hand.
3. Position the seat post tube to your desired height and align the holes.
4. Replace the bolt and secur
e by tightening the nut.
5. Replace the seat by holding the release lever, and inserting the seat onto the seat post assembly.
6. Ensure that the seat is fully engaged and that it rotates and locks correctly.
Electric Seat Height Adjustment
When the seatlift accessory is installed, the seat height can be adjusted electrically. The seatlift rocker switch is
on the bottom left hand side of the dash, above the horn (see page 7). To raise and lower the seat:
1. Push the rocker switch into the up position
2. Pull the right finger control lever towards you to raise the seat
3. Put the left hand finger control towards you to lower the seat. Never pull both levers together.
4. Switch off the electric seat height adjustment by pushing the rocker switch into the down position.
Warning! The seat is heavy. If necessary get assistance to lift the seat. You may prefer to ask your Dealer
to adjust your seat height
Warning! For your safety, the scooter will not operate when seatlift is selected. Always ensure that the
seatlift switch is in the off position after adjusting the seat height. Never leave it selected.
