Technical Specification - Rascal 600T Scooter
Wheelchair type Class Class A, B or C Class B
Department of Transport Class Class 1 2 or 3 Class 2
Overall dimensions fully assembled
length x width x height mm (in) 1170 (46) x 635 (25) x 980 (38.6)
Dimensions seat removed tiller folded length x width x height mm (in) 1170 (46) x 635 (25) x 600 (23.6)
Maximum carrying capacity kg (lb) 204 (450)
Mass (weight) including batteries
kg (lb) 93 (206)
Battery voltage and capacity volts and ampere hours 12V 40Ah x 2
Mass (weight) of battery (each) kg (lb) 15.6 (34)
Type of seat Adjustable armrest and height, backrest
and swivel mounting
Mass (weight) of seat kg (lb) 14 (32)
Mass (weight) of front section kg (lb) 11 (25)
Mass (weight) of rear section* kg (lb) 14.2 (31.2)
Mass (weight) of tiller kg (lb) 3.5 (7.8)
Mass (weight) of gearbox and motor drive train kg (lb) 19.5 (43.4)
Wheel size front/rear mm (in) 254 x 76 (10 x 3) / 254 x 76 (10 x 3)
Type of tyres type Pneumatic
Tyre pressures normal front/rear mm (in) 30/30 psi (2 bar)
Tyre pressure maximum - not to be exceeded front/rear mm (in) 35/35 psi (2.3 bar)
Maximum speed km/h (m.p.h.) 6.4 (4)
Minimum braking distance fr
om maximum speed
m (ft)
1.6 (5.4)
Range on full charge and flat ground km (miles) Up to 40 (25)
The tur
n-ar
ound width m (ft) 2.6 (8.5)
The maximum safe slope
degr
ees of slope
10˚ - Do not exceed the scooter may topple
The maximum climbing ability facing upwards degrees of slope 14˚
Gr
ound clearance mm (in) 80 (3)
Maximum obstacle climbing ability
mm (in)
50 (2)
Maximum safe descendable kerb height mm (in) 50 (2)
* without seat, gearbox and motor drivetrain
