Electric Mobility Rascal Mobility Vippi - Technical Specification

Technical Specification - Rascal Vippi Scooter
NOTE: This scooter meets the relevant requirements of ISO 7176:14 2008
*Range on full charge and flat ground.
**Do not charge battery outside this temperature range. Doing so can permanently damage battery.
Due to a policy of continual improvement, Electric Mobility Euro Ltd. reserves the right to change specifications without pri
or
notice.
25
Wheelchair type Class A, B or C Class B
Department of Transport class Class 1, 2 or 3 Class 2
Overall dimensions fully assembled
length x width x height mm (in) 1000 (39.4.) x 495 (19.5) x 890 (35.0)
Dimensions seat back and tiller folded length x width x height mm (in) 1000 (39.4.) x 495 (19.5) x 450 (17.7)
Maximum carrying capacity Kg (lbs) ((stone)) 130 (286) ((20.4))
Mass (weight) including 14Ah batteries Kg (lbs) 43.6 (96.1)
Mass (weight) of heaviest part Kg (lbs) 15.4 (33.9)
Mass (weight) of battery pack Kg (lbs) 9.9 (21.8)
Maximum shopping basket load Kg (lbs) 4.5 (9.9)
Battery voltage and capacity Volts and Ampere-hours 12V / 14Ah x 2
Type of seat Comfort seat with folding backrest and adjustable arms
Mass (weight) of seat Kg (lbs) 7.9 (17.4)
Wheel dimensions front
mm (in) 190 (7.5) × 50 (2)
Wheel dimensions rear
mm (in) 200 (7.9) × 50 (2)
Type of tyres Solid foam filled - puncture proof
Maximum speed Km/h (m.p.h.) 6.4 (4)
Minimum braking distance at max. speed m (ft) 0.94 (3.1)
Range* Km (miles) 19.1 (11.9)
Turn-around width m (ft) 1.35 (4.4)
Maximum safe slope Degrees of slope
6° -Do not exceed scooter may topple
Maximum climbing ability facing forward Degrees of slope
6°
Ground clearance mm (in) 35
Maximum obstacle climbing ability mm (in) 50 (2)
Maximum safe descendable kerb height
mm (in)
50 (2)
Force to operate accelerator control
Newtons (lbf)
3.2 (0.72)
Force to operate freewheel lever Newtons (lbf) 58.8 (13.2)
Ambient operating temperature range** °C (°F) 2 (35.6) to 40 (104)
