Electro-Voice CPS 1 - 10. Factory default; 11. Noise interference; 12. Dimensions and weight

4
10. Factory default
BRIDGED MODE switch set to NORMAL
INPUT ROUTING switch set to DUAL/STEREO
LEVEL controls set at their clockwise margin.
11. Noise interference
- U(F) = external voltage un-weighted with B = 22 Hz … 22 kHz, effective value (IEC 268-1)
- U(G) = noise voltage, frequency-weighting filter according to CCIR-468-3, quasi peak weighted (IEC 268-
1)
- U(A) = interference voltage A-weighted, dB(A), effective value (IEC 268-1)
- Signal-to-noise ratio referring to maximum output voltage at 4 Ω and A-weighted interference voltage
Power Amp output U(F)
dBu
U(G)
dBu
U(A)
dBu
GAIN
dB
IN(A)
dBu
S/N-R.
dB
remarks
LEVEL controls set to their clockwise margin
CPS1 SPEAKER
OUT A&B -67 -56 -69 32.5 -102.5 105
INPUT A&B
R(Q) = 50Ω
CPS2 SPEAKER
OUT A&B -67 -56 -69 33.5 -102.5 105
INPUT A&B
R(Q) = 50Ω
LEVEL controls set to their counterclockwise margin
CPS1 SPEAKER
OUT A&B -68 -57 -70 / / /
INPUT A&B
R(Q) = 50Ω
CPS2 SPEAKER
OUT A&B -68 -57 -70 / / /
INPUT A&B
R(Q) = 50Ω
12. Dimensions and weight
Power amplifier weight Dimensions in mm
CPS1 15kg 483 x 132.5 x 385.5
CPS2 16kg 483 x 132.5 x 385.5
