Equipment Capacity
Dx 38 configuration * OS V1.05, might change w/o prior notice
Comments Options
System Applications Xi Series
Clubs, Top 40 Bands
3.4
3-Way Stereo
Cabinets: 2 x Xi 2123, 4 x Xi 2181 Horizontal coverage: 2 x 100°
Amps: 2 x P2000, 2 x P3000 Average distance: 25 meters
Cabeling: 4 x NL8 long Total amp. power: 7,000 Watts
Dx38: 2
Dx38 In 1 In 2 Out 1 Out 2 Out 3 Out 4 Preset *
#1 Main Left Mid L Hi L Lo L #49(Out1&2) #42(Out4, 2181)
#2 Main Right Mid R Hi R Lo R #49(Out1&2) #42(Out4, 2181)
Preset #49 is overlapped mode for maximum vertical
directivity. For max. SPL use 250 Hz X-Over setting.
Xi 2123 could be rotated by 90° if height ist limited. Spare
Input on Dx38 could be used for separate mono feed.
System could be upgraded to 4-way Stereo.
(Xi 2123 triamp mode – needs additional P1200).
L: 2 x 12” L:10” + 2”
L: 2 x 18 “ L:2 x 18 “
Left Spare
R: 2 x 12” R:10” + 2”
R: 2 x 18 “ R:2 x 18 “
Right Spare
