Equipment Capacity
Dx 38 configuration * OS V1.05, might change w/o prior notice
Comments Options
System Applications Xi Series
Clubs, Smaller Venues, Top 40 Bands
3.3
3-Way Stereo
Cabinets: 4 x Xi 1152/64, 4 x Xi 2181 Horizontal coverage: 2 x 100°-120°
Amps: 4 x P 3000 Average distance: 20-25 meters
Cabeling: 2 x NL4 long/short, 2 x NL8 long/short Total amp. power: 7,900 Watts
Dx38: 2
Xi 1152
Xi 1152
Xi 1152
Xi 1152
L: 15” L:2”
L: 2 x 18” L:2 x 18”
Dx38 In 1 In 2 Out 1 Out 2 Out 3 Out 4 Preset *
#1 Main Left Lo L Mid L Hi L #38 (change Out1 to 2181-see#42)
#2 Main Right Lo R Mid R Hi R #38 (change Out1 to 2181-see#42)
Xi 1152 could be positioned for dedicated horizontal
angles
P3000 can be used through out.
R: 15” R:2”
R: 2 x 18” R:2 x 18”
