Cabinets: 4 x Xi 1183, 2 x Xi 2181, 4 x Xi 1191 Horizontal coverage: 2 x 120°-130°
Amps: 5 x P 3000 Average distance: 30 - 35 meters
Cabeling: 3 x NL8 long, 7 x NL8 short Total amp. power: 10.200 Watts
Dx38: 2
L: 12 “ L:2 “
L: 18 “ L:18 “
S: 18 “ S:18 “
Connect to OP
R: 12 “ R:2 “
R: 18 “ R:18 “
Equipment Capacity
Dx 38 configuration * OS V1.05, might change w/o prior notice
Comments Options
System Applications Xi Series
3-Way Stereo+Sub
Small to medium Venue, wide • Concert Sound
4.1
Left Sub
Right Spare
D x 3 8 In 1 In 2 Out 1 Out 2 Out 3 Out 4 Preset *
# 1 Main Left S u b S u b Lo L Mid L Hi L #50 (Out1, route to In2), #42 (Out2: HP from 80Hz to 50Hz)
# 2 Main Right Lo R Mid R Hi R #42 (Out2: HP from 80Hz to 50Hz)
To Next Page
