Equipment Capacity
Dx 38 configuration * OS V1.05, might change w/o prior notice
Comments Options
System Applications Xi Series
Medium Venue, wide • Musical/Theatre
4.2
3-Way LCR+Sub
Cabinets: 3 x Xi 2123, 4 x Xi 1191, 4x Xi 1082 Horizontal coverage: 3 x 100°
Amps: 2 x P 1200, 3 x P2000, 1 x P3000 Average distance: 20 - 25 meters
Cabeling: 5 x NL8 long, 6 x NL8 short Total amp. power: 6,300 Watts
Dx38: 3
Dx38 In 1 In 2 Out 1 Out 2 Out 3 Out 4 Preset *
#1 Main Left Sub Lo L Mid L Hi L Sub #50 (route Out4 to In2)
#2 Center Lo C Mid C Hi C #50
#3 Right Fill Lo R Mid R Hi R Fill #50 (route Out4 to In2, clear Out4 filters)
MF and HF horns could be rotated for vertical use.
2 Xi 2181 could be used alternatively.
Sub: 2 x 18” Sub:2 x 18”
L C R
L: 2” C:2”
L: 10” C:10”
L: 2 x 12” C:2 x 12”
Left Sub
Center
Fill: Xi 1082 R: 2 “
R: 2 x 12” R: 1 x 10 “
Right Fill
4 x Xi 1082
