Cabinets: 8 x Xi 1183, 4 x Xi 2181 Horizontal coverage: 2 x 120°-130°
Amps: 6 x P 3000 Average distance: 40 - 50 meters
Cabeling: 4 x NL8 long, 8 x NL8 short Total amp. power: 14,400 Watts
Dx38: 2
L: 12” L:2”
L: 18” (1183) L:18” (1183)
L: 2 x 18” (2181) L: 2 x 18” (2181)
R: 12” R:2”
R: 18” (1183) R:2” (1183)
R: 2 x 18” (2181) R:2 x 18” (2181)
Equipment Capacity
Dx 38 configuration * OS V1.05, might change w/o prior notice
Comments Options
System Applications Xi Series
4-Way Stereo
5.1
Left Spare Right
Spare IP or Dx38 could be used for separate mono
feed from console.
Dx38 In 1 In 2 Out 1 Out 2 Out 3 Out 4 Preset *
#1 Main Left Sub L Lo L Mid L Hi L #42
#2 Main Right Sub R Lo R Mid R Hi R #42
