26
RE3-RX receiver
RE3 UHF
-12 | 01 | F.01U.362.808 Installation manual Electro-
3
Scroll through groups using the ▲ or ▼ buttons noting open
channel quantity per group. Select either the same previous group
or a new group by pressing SET. This advances to the channel
and CH # highlights.
4
Press the ▲ or ▼ button to scroll through open channels. Note
that some channel numbers may be skipped because they were
not clear at the time of the scan.
Press SET on CH number.
This selects that group and channel the set will operate on.
5 This also returns to Result List on the scan menu.
6
Either scroll ▼down to Exit and press SET, or briefly press SYNC
on the receiver front panel to escape to the home screen. The
selected Group/Channel and associated Frequency displays on
the home screen.
OR
7.3.5 Scanning current group
The current assigned group, or a particular selected group can be scanned individually. This
process will locate clear channels within that group individually.
1 Enter the main menu and select Scan by pressing SET.
2
Press the ▼ button to scroll down to Current Group. Press SET to
enter Result List.
3
The current assigned group is displayed. Prepare to scan that
group, or scroll through other groups using ▲ or ▼. Select the
group to scan by pressing SET. The scan of that group begins.
When the scan is complete, the highlight box advances to
channel, and the first clear channel in that group appears.
4
Either press SET to save the channel displayed and exit, or press
▲ or ▼ to scroll through to locate the next open channel. A brief
scan occurs while locating the next clear channel. Some channel
numbers may be skipped because they were not clear at the time
of the scan. Press SET to save. This selects that group and
channel the set will operate on.
