28
RE3-RX receiver
RE3 UHF
-12 | 01 | F.01U.362.808 Installation manual Electro-
3
The three digits to the right of the decimal are in thousands (kHz).
Pressing ▲ increases frequency in increments of 25 kHz per
press, ▼decreases frequency in increments of 25 kHz per press.
The G:__ and CH:__ under the frequency will populate when a
preset group and channel match the frequency dialed in.
4
Press SET to save the custom frequency and to exit to the main
menu.
5
Either scroll ▼down to Exit and press SET, or briefly press SYNC
on the receiver front panel to return to the home screen. The
selected custom Frequency displays on the home screen.
OR
7.3.8 Manually setting group and channel
Setting group and channel manually does not benefit from the scan function of locating clear
channels. It is important to note that manually entered group/channel combination may experience
interference, which can be avoided by using the scan function.
1
Press the ▼ button to scroll down to Group/Channel on the main
menu. Select by pressing SET to enter the Setup Group screen.
2
The current selected group number is highlighted. Pressing ▲
increases the group number (1-8) in single digit increments, and
pressing ▼ decreases the group number (1-8) in single digit
increments. Press SET to move to Channel.
3
The current selected channel number is highlighted. Pressing ▲
increases the channel number (up to max of 22) in single digit
increments, and pressing ▼ decreases the channel number in
single digit increments. The frequencies above the G:__ CH__
change to display the frequency of the changed group and
channel.
4
Press SET to save the chosen Group/Channel and return to the
main menu.
5
Either scroll ▼down to Exit and press SET, or briefly press SYNC
on the receiver front panel to return to the home screen. The
selected custom Frequency displays on the home screen.
OR
