Xds Double Subwoofer System
equalization, signal delay, compressor-lim-
iter-and noise-gate functions. Program pa-
rameters for optimal performance of the
X-Array™ systems are available. Klark
Teknik, Klark Industrial Park, Walter Nash
Road, Kidderminster, Worcestershire DY11
7HJ England, 44-156-274-1515
Electro-Voice Dx38 Digital Controller:
The Dx38 digital electronic loudspeaker
controller has a two-in/four-out architecture,
with each output having programmable high-
pass and low-pass filters, four-band equal-
ization, signal delay compressor and lim-
iter functions. Program parameters for op-
timal performance of the X-Array™ sys-
tems are available. Electro-Voice, 600 Cecil
St., Buchanan, MI 49107 USA, 616/695-6831
Electro-Voice P3000 Power Amplifiers:
The stereo P3000 power amplifiers are rated
at 800 watts into 8 ohms, or 93-volts rms
short term. The amplifiers are 3-U high and
weigh 28 kg (62 lb) each. EVI Audio, 600
Cecil St., Buchanan, MI 49107 USA,
616/695-6831
X-Array™ Amplifier Racks: These 16-U
racks will hold four Electro-Voice P3000
power amplifiers, one Klark Teknik DN8000
digital controller, 1-U light module, and a 2-
U multipin patch panel. The aluminum-
frame/wood-panel racks are vibration-isola-
tion mounted on heavy-duty wheel boards
and come prewired for AC power, audio and
control signal sends and Neutrik
®
Speakon
speaker connectors. db Sound, L.P., 1219
Rand Road, Des Plaines, IL 60016 USA,
847/299-0357
X-Array™ Speaker Cables: Eight conduc-
tor cable with four #11 AWG conductors and
four #13 AWG connectors. The larger con-
ductors are used in the LF bands for in-
creased damping factor. Lengths made to
order. Standard terminations are Neutrik
Speakon
TM
NL8FC connectors wired to
X-Array™ standards; however, custom
terminations are available. Entertainment
Technology Cable, 1247 Rand Road,
Des Plaines, IL 60016 USA, 800/529-6312
Miscellaneous Accessories:
X-Array™ Loudspeaker Covers: Heavy-
duty covers are available for the X-Array™
speakers. These covers wrap around the
enclosures, while sitting on a dolly, and
Velcro together at the back for fast instal-
lation and removal. db Sound, L.P., 1219
Rand Road, Des Plaines, IL 60016 USA,
847/299-0357
X-Array™ Dolly Boards: Double-wide
dolly built to hold four X-Array™ loud-
speakers, two wide by two high. The double-
thick 18-mm birch-plywood construction
includes cutouts and keys for loudspeaker
enclosure shape and alignment feet. The
dolly boards are painted black and utilize
four extra-heavy-duty 4-inch x 2-inch cast-
ers. Custom-designed dolly boards are also
available to meet specific requirements.
R&R Cases and Cabinets, 1217 Rand Road,
Des Plaines, IL 60016 USA, 847/299-8100
Racks and Road Cases: A variety of gen-
eral purpose, custom racks and hard-shell
road cases are available for touring or per-
manent-installation applications. R&R Cases
and Cabinets, 1217 Rand Road, Des Plaines,
IL 60016 USA, 847/299-8100
Limited Warranty
Electro-Voice products are guaranteed
against malfunction due to defects in mate-
rials or workmanship for a specified period,
as noted in the individual product-line
statement(s) below, or in the individual prod-
uct data sheet or owner’s manual, beginning
with the date of original purchase. If such
malfunction occurs during the specified pe-
riod, the product will be repaired or replaced
(at our option) without charge. The product
will be returned to the customer prepaid. Ex-
clusions and Limitations: The Limited
Warranty does not apply to: (a) exterior fin-
ish or appearance; (b) certain specific items
described in the individual product-line
statement(s) below, or in the individual prod-
uct data sheet or owner’s manual; (c) mal-
function resulting from use or operation of
the product other than as specified in the prod-
uct data sheet or owner’s manual; (d) malfunc-
tion resulting from misuse or abuse of the
product; or (e) malfunction occurring at any
time after repairs have been made to the
product by anyone other than Electro-Voice
Service or any of its authorized service rep-
resentatives. Obtaining Warranty Ser-
vice: To obtain warranty service, a cus-
tomer must deliver the product, prepaid, to
Electro-Voice Service or any of its autho-
rized service representatives together with
proof of purchase of the product in the
form of a bill of sale or receipted invoice. A
list of authorized service representatives
is available from Electro-Voice Service at
600 Cecil Street, Buchanan, MI 49107
(800/234-6831 or FAX 616/695-4743). Inci-
dental and Consequential Damages Ex-
cluded: Product repair or replacement and
return to the customer are the only rem-
edies provided to the customer. Electro-
Voice shall not be liable for any incidental
or consequential damages including, with-
out limitation, injury to persons or prop-
erty or loss of use. Some states do not
allow the exclusion or limitation of inciden-
tal or consequential damages so the above
limitation or exclusion may not apply to
you. Other Rights: This warranty gives
you specific legal rights, and you may also
have other rights which vary from state to
state.
Electro-Voice Speakers and Speaker Sys-
tems are guaranteed against malfunction due
to defects in materials or workmanship for a
period of five (5) years from the date of origi-
nal purchase. The Limited Warranty does not
apply to burned voice coils or malfunctions
such as cone and/or coil damage result-
ing from improperly designed enclosures.
Electro-Voice active electronics associ-
ated with the speaker systems are guaran-
teed for three (3) years from the date of origi-
nal purchase. Additional details are included
in the Uniform Limited Warranty statement.
Electro-Voice Accessories are guaranteed
against malfunction due to defects in ma-
terials or workmanship for a period of one
(1) year from the date of original purchase.
Additional details are included in the Uni-
form Limited Warranty statement.
For warranty repair or service informa-
tion, contact the service repair department
at: 616/695-6831 or 800/685-2606.
For technical assistance, contact Technical
Support at 800/234-6831 or 616/695-6831,
M-F, 8:00 a.m. to 5:00 p.m. Eastern Stan-
dard Time.
Specifications subject to change without
notice.
