Electro-Voice Xds - Figure 1 - Polar Response

Xds Double Subwoofer System
Xds Double Subwoofer System
5
Vertical
Horizontal
5 dB per division
Xds Double Subwoofer System
Figure 1 — Polar Response
The directional response of the Xds was measured in an anechoic environment at a distance of 6.1 m (20 ft.) using 1/3-octave-filtered pink
noise with a full spherical measurement system. The polar response of the loudspeaker system at selected 1/3-octave frequencies is
shown. The selected frequencies are representative of the polar response of the system.
63 Hz 80 Hz 100 Hz
160 Hz 200 Hz125 Hz
