Electrolux Built-in ovens Instruction Book

78
Fig. 12
Fig. 13
Oven door cleaning
For a better cleansing of the oven door, you are
suggested to remove it from the appliance with
the following procedure:
- open tho door completely; lift the small levers
placed on the two hinges and turn the levers
towarde the inside (Fig. 11).
- Slowly close the oven door, until it touches
the two levers,
- then push it towards the oven and remove
it by pulling it towards the outeide.
- Place the door on a horizontal level.
After cleaning, assemble the door again by
carrying out the procedure described above
backwards. When the two small levers are
placed again on the hinges, the door will have
been accurately fit.
Replacing the oven light
Disconnect the appliance from its power supply
point. Push in and unscrew the glass cap (Fig.
12). Unscrew the light bulb and replace it with
a new heat-proof bulb (300°C) having the
following features: - Operative tension: 230 V
(50 Hz); - Power: 25 W; - Fitting: E 14.
Reconnect the appliance.
The Hinged Grill
Some models are fitted with a hinged grill
element, to enable you to clean the roof of the
oven easily.
Before proceeding ensure the oven
is cool and is isolated from the
electricity supply.
z Undo the screws which hold the grill in place
(see Fig. 13). When doing this operation
for the first time, we recommend using a
screwdriver.
z Then gently pull the grill downward to allow
access to the oven roof.
z Clean the oven roof with a suitable cleaner
and wipe dry before replacing the hinged
grill element.
z Gently push up the grill element into place
and firmly screw into place the holding nuts.
Fig. 11
FO 0452
Ensure the grill holding nuts are
firmly in place to avoid the grill
falling down when in use.
