6. Left Front Cooking Zone Control Pads.
7. Left Rear Cooking Zone Control Pads.
8 Central Cooking Zone Control Pads.
9. Right Rear Cooking Zone Control Pads.
10. Right Front Cooking Zone Pads.
11. Main Cooktop Controls (See Fig 2).
12. Cooktop Power Key Pad (See p. 9).
13. Cooktop Power Indicator Light (See p. 9).
14. Keep Warm Setting Key Pad (See pages 10 & 16).
15. Controls Lock Key Pad (See pages 9 & 17).
16. Controls Lockout Indicator Light (See pages 9 & 17).
17. Minute Timer Setting + (increase) / - (decrease) Key Pads (See pages 16 & 17).
18. Minute Timer LED (displays up to 99 minutes - (See pages 16 & 17).
19. Cooking Zone ON/OFF Key Pad (for each Cooking Zone).
20. Cooking Zone ON/OFF Indicator Light (for each Cooking Zone).
21. Cooking Zone + (increase) Key Pad (for each Cooking Zone).
22. Cooking Zone - (decrease) Key Pad (for each Cooking Zone).
23. Cooking Zone Power Level LED (for each Cooking Zone).
Induction Cooktop Features
INDUCTION COOKTOP FEATURES (CONT’D)
Fig 3.
Fig 2.
On/Off
19
20
212223
Cooking Zone Controls
(at 5 locations)
6 7 8 9 10
POWER
12
13
1415
16
17
18
Main Cooktop Controls
11
