17. TECHNICAL SPECIFICATIONS
s regards the general dimensions of the machine, please see the fig. D
eating element
FUSES
A
Width 594 mm •
Depth 260 mm •
Height 378 mm •
Capacity of water reservoir 2.5 l •
Net weight 17 kg •
Gross weight 19 kg •
Supply voltage 230 V •
Rated power 1150 W •
Power absorbed by the h 1000 W •
Power absorbed by the pump 50 W •
Working pressure 12 bar •
Fuse 10 A •
F1: Fuse Ø 5 x 20 mm - Vn = 250 V - In=10 A
2: Fuse Ø 5 x 20 mm – Vn = 250 V – In = 0.5 A
F
37
