22
3. Remove foil hose and polystyrene padding from
the machine.
Electrical connection
Details on mains voltage, type of current and the fus-
es required should be taken from the type plate. The
type plate is fitted near the loading aperture (see
“Machine description” section).
Changing door stop
1
Warning! The door stop may only be changed
by a specialist. If necessary, please contact
our after-sales service or your specialist deal-
er.
Warning! Before changing the door stop, dis-
connect the mains plug; with a permanent
connection: fully unscrew or deactivate the
fuse.
1. Open loading door
2. Unscrew hinge A from the front of the machine and
take off the loading door.
3. Remove cover plates B and C. To do this, insert a
thin screwdriver into the slots as shown in the illus-
tration, press downwards slightly and pry out the
cover plates.
4. Use an appropriate tool and exert pressure to un-
fasten locking block D from the snap-on fixture,
take out and reinsert on the other side, having ro-
tated the block through 180°.
5. Unscrew hinge A from the loading door, rotate
through 180°, reinsert on the opposite side and
screw down.
6. Reinsert cover plates B and C on the opposite site
having first rotated them through 180°.
