Description of machine
Operating screen
Drawer containing
condensate tank
Screwed feet
(with height
adjustment)
Loading door
(interchangeable stop)
Operating screen
Large mesh filter
(lint filter)
Air slots
Lamp for inside light
Type plate
Base door
upstream of
heat exchanger
M
icro-fine filter
(
lint filter)
Fine strainer
(lint filter)
Programme progress display
Programme selector
Maintenance displays
– HEAT EXCHANGER (WÄRMETAUSCHER - clean!)
– EMPTY WATER (BEHÄLTER - empty!)
– CLEAN FILTER (SIEB - clean fluff filter!)
Block of buttons
and displays
