4. PRODUCT DESCRIPTION
1 2
6
3
4
5
8
9
10
11
7
1
Water container
2
Control panel
3
Appliance door
4
Primary Filter
5
Button for condenser door
6
Airflow slots
7
Adjustable feet
8
Condenser door
9
Condenser cover
10
Locks for condenser lid
11
Rating plate
The load door can be
installed by the user in the
opposite side. It can help to
easily put and remove the
laundry or if there is a limit to
install the appliance (see
separate leaflet).
5. CONTROL PANEL
1 2
7
3
6
5
4
8
1
Programme knob
2
Display
3
Time touchpad
4
Delay touchpad
5
Delicate touchpad
6
Wool Load touchpad
7
Start/Pause touchpad
8
On/Off button
ENGLISH 7
