Installation electrolux 7
EN
Connections
Connection in Extraction Mode
When installing in extraction mode, con-
nect the hood to the chimney using ei-
ther a exible or rigid pipe ø 150 or 125
mm, the choice of which is left to the
installer.
• To install a ø 125 mm air exhaust con-
nection, insert the reducer ange G
on the hood body air outlet and the
adapting ring ø120-125 F on the re-
ducer ange.
• Fix the pipe in position using sufcient
pipe clamps (not supplied).
• Remove any activated charcoal l-
ters.
Connection in Recirculation Mode
• When the hood is tted in the recircu-
lation mode the Air Outlet Connection
H should be tted as illustrated .
• Fit the (optional) charcoal lters by
repeating the following operation on
each side of the motor housing. Place
the two key hole slots in the lter and
turn the lter clockwise to lock the
lter in position.
WARNING: It is a possible re hazard if
the metal grease lters are not cleaned
and the charcoal lters replaced regu-
larly.
IMPORTANT:
When installing this product in recircula-
tion mode over a gas hob or Gas coo-
ker and between adjacent wall mounted
cupboards. The installer must ensure
that there is no gap between the edge
of the canopy and wall cup-boards.
