16 electrolux INSTALLING THE COOKER HOOD
EN
INSTALLING THE COOKER HOOD
Please ensure that when the
appliance is installed it is easily
accessible to an engineer in the
event of a breakdown.
All installations must comply with the
local authorities requirements for the
discharge of exhaust air.
Incorrect installation may affect the
safety of this cooker hood.
Installation Requirements
Before fi tting the hood beneath
any type of canopy or wall cabinet,
ensure that the housing is fi rmly fi xed
to the wall in accordance with the
manufacturer’s instructions.
If it is necessary to fi x the housing for
the canopy to a hollow construction
plaster or partition board structure then
it should be suffi ciently reinforced to
be quite rigid in the area of the cabinet
housing fi xings.
Ducting
The ducting must be fi re retardant
125mm (5ins) in diameter and the length
should be no more than:
3 metres with one 90° bend
2 metres with two 90° bends
Bends of more than 90° will reduce the
effi ciency of the hood and reduce the
airfl ow.
Clearance Height
The cooker hood is designed to be
fi tted over a cooking appliance at the
clearance heights stated, providing
the maximum output of the appliance
beneath does not exceed the maximums
quoted in the Technical Specifi cations.
If the output of the appliance below the
cooker hood exceeds the maximum
outputs quoted, please refer to the
cooker manufacturer’s installation
instructions.
Clearance Height
A clearance height of 650mm (25 1/2 ”)
is required when installed above a built-
in electric hob, or 700mm (27 1/2 ”)
when installed above a built-in gas hob.
A clearance height of 685mm (27”)
is required when installed above a
slot-in electric cooker, or 787mm (30
1/2 ”) when installed above a slot-in gas
cooker.
