Electrolux EHE6899SA - Page 11

ARESI1006
 Copyright 2018 ELECTROLUX HOME PRODUCTS PTY LTD Technical Services
23
Fresh Food
Door
Open/Close FF
Reed Switch
a. On the Display it shows “CL” when
door closed; “OP” when is open.
24
Freezer
Drawer
Open/Close FZ
Reed Switch
a. On the Display it shows “CL” when
door closed; “OP” when is open.
25
VCZ Drawer
Open/Close VCZ
Reed Switch
a. On the Display it shows “CL” when
door closed; “OP” when is open.
28
Dispenser
Paddle
Press the
Dispenser Paddle
a. On the Display it shows “oF” when
door closed; “on” when is open.
29
Fresh Food
Sensor
Activates
Automatically
a. On the Display it shows temperature
sensed by FF Sensor.
b. It is displayed in °C or °F according to
UI selection of the temperature
representation.
c. “OP” if open-circuit; “SH” if short-
circuit.
30
Freezer
Sensor
Activates
Automatically
a. On the Display it shows temperature
sensed by Freezer Sensor.
b. It is displayed in °C or °F according to
UI selection of the temperature
representation.
c. “OP” if open-circuit; “SH” if short-
circuit.
31
Fresh Food
Evap Defrost
Sensor
Activates
Automatically
a. On the Display it shows temperature
sensed by Fresh Food Evaporator
Defrost Sensor.
b. It is displayed in °C or °F according to
UI selection of the temperature
representation.
c. “OP” if open-circuit; “SH” if short-
circuit.
32
VCZ Sensor
Activates
Automatically
a. On the Display it shows temperature
sensed by VCZ Sensor.
b. It is displayed in °C or °F according to
UI selection of the temperature
representation.
c. “OP” if open-circuit; “SH” if short-
circuit.
33
Ambient
Temperature
Sensor
Activates
Automatically
a. On the Display it shows temperature
sensed by H&T sensor regarding the
Ambient Temperature.
b. It is displayed in °C or °F according to
UI selection of the temperature
representation.
c. “OP” if open-circuit; “SH” if short-
circuit.
Displayed
code
Function
Test
Action
Available
Behavior Expected
