Electrolux EHE6899SA - Page 12

ARESI1006
 Copyright 2018 ELECTROLUX HOME PRODUCTS PTY LTD Technical Services
39
Freezer
Evaporator
Defrost
Sensor
Activates
Automatically
a. On the Display it shows temperature
sensed by Freezer Evaporator
Defrost Sensor.
b. It is displayed in °C or °F according to
UI selection of the temperature
representation.
c. “OP” if open-circuit; “SH” if short-
circuit.
45
Icemaker
Tray Sensor
Activates
Automatically
a. On the Display it shows temperature
sensed by IceMaker Tray Sensor.
b. It is displayed in °C or °F according to
UI selection of the temperature
representation.
c. “OP” if open-circuit; “SH” if short-
circuit.
68
Icemaker
Evaporator
Defrost
Sensor
Activates
Automatically
a. On the Display it shows temperature
sensed by IceMaker Evaporator
Defrost Sensor.
b. It is displayed in °C or °F according to
UI selection of the temperature
representation.
c. “OP” if open-circuit; “SH” if short-
circuit.
64
Humidity
Sensor
Activates
Automatically
a. On the Display it shows relative
Humidity sensed by H&T sensor in %.
b. “OP” if open-circuit; “SH” if short-
circuit.
At the end of all the Function Tests, one section is dedicated to the visualization of the ID-string or
software version of all the electronic boards that are present in the appliance.
When the last item of Test Functions is visualized, pressing again the + button to progress, it will
start automatically to display “--” on the display and after this it will start the sequence described
below.
Between 2 items (i.e Software Parameters and Main Board Firmware Version) it will be displayed
again a “--” character, used as separator.
a-
Software
Parameters
Runs Automatically,
scrolling all the digits
of the string.
a. Displays digits sequence related to the
set of parameters that is flashed inside
erf2600 power board;
b. It is built of 8 digits.
c. For Example: “00499539”
d. Press + button if you want to skip this
visualization and pass to the next
record.
b-
Main Board
Firmware
Version
Runs Automatically,
scrolling all the digits
of the string.
a. Displays digits sequence related to the
ID string or firmware version of erf2600
power board
b. It is built of 8 digits
c. For Example: “JHB10G10”
Display
code
Function
Test
Action Available
Behavior Expected
