Electrolux EHE6899SA - Page 8

ARESI1006
 Copyright 2018 ELECTROLUX HOME PRODUCTS PTY LTD Technical Services
18
Condenser
Fan
Press (MODES) to
change the status
of the Function
a. It is possible to run the Condenser
Fan at 3 possible speeds.
b. Fan running maximum speed when
“on”; medium speed when “nL”;
stopped when “oF”
c. Press (MODES) button to change the
status.
d. In case of Locked rotor condition
the display shows “LC”
e. In case of absence of PWM signal
that provide duty cycle, the display
shows “nS” when the fan is “OF”.
f. In case of absence of 12V signal or
GND signal, the display shows “nP”
when the fan is “on” or “Mi”.
20
Freezer Light
Press (MODES) to
change the status
of the Function
a. Freezer light on when “on”, off when
“oF”
b. Press (MODES) button to change the
status.
38
VCC
Compressor
Press (MODES) to
change the status
of the Function
a. Compressor is running at maximum
speed when “on”, it is stopped when
“oF”.
b. Press (MODES) button to change the
status.
47
Ice Chute
Heater
Press (MODES) to
change the status
of the Function
c. Chute Heater is activated when “on”,
deactivated when “oF”.
d. Press (MODES) button to change the
status.
62
Icemaker
Evaporator
Fan
Press (MODES) to
change the status
of the Function
a. ”on” is showed in the display when
icemaker evap fan is activated, “oF” is
showed when the fan is deactivated.
b. Press (MODES) button to change the
status.
63
Flip Mullion
Heater DC
Press (MODES) to
change the status
of the Function
a. DC Flip Mullion Heater is activated
when “on”, deactivated when “oF”
b. Press (MODES) button to change the
status.
66
Dispenser
Light
Press (MODES) to
change the status
of the Function
a. Dispenser light on when “on”, off
when “oF”
b. Press (MODES) button to change the
status.
70
Fresh Food
Evaporator
Fan
Press (MODES) to
change the status
of the Function
a. It is possible to run the Fresh Food
Evaporator Fan at 3 possible speeds.
b. Fan running maximum speed when
“on”; medium speed when “nL”;
stopped when “oF”
Displayed
code
Function
Test
Action
Available
Behavior Expected
