c. Press ( MODES) button to change the
status.
d. In case of Locked rotor condition
the display shows “LC”
e. In case of absence of PWM signal
that provide duty cycle, the display
shows “nS” when the fan is “OF”.
f. In case of absence of 12V signal or
GND signal, the display shows “nP”
when the fan is “on” or “Mi”.
Heater
change the status
of the Function
a. VCZ Damper Heater is activated
when “on”, deactivated when “oF”.
b. Press (MODES) button to change the
status.
change the status
of the Function
a. It is automatically turned on the
Freezer Evaporator Fan at
maximum speed.
b. When VCZ Damper is open it shows
“OP”, when close it shows “CL”.
c. Then check for air flow when damper
is fully open “OP”; and no air leaks
when fully closed “CL”.
d. During the movement of damper, it
blinks a “1”.
e. If the Freezer evaporator fan presents
some errors during its movement, it is
alternatively displayed the error status
of the fan (LC, nS, nP) and the status
of the damper (OP, CL).
f. Press (MODES) button to change the
status and open/close the damper.
Door/ Ice
Flapper
Motor
change the status
of the Function and
moves the flapper
motor.
a. When the flapper motor is closed, it
shows “CL”.
b. When the ice chute door is opened, it
shows “OP”.
c. During the movement of the flapper
motor, it blinks a “1”.
d. The tentatives of opening/closing the
ice chute door are performed
recursively for 3 consecutive times
and in case of failure it shows “Er”.
e. Press (MODES) button to change the
status.
Twist Tray
Harvest Test
change the status
of the Function and
start the rotation.
a. Remove the Ice Bucket in order to
see clearly the rotation of the ice
tray.
b. On the Display it shows “Go” when
the tray find the home position
(Horizontal position).
c. During the rotation of the ice tray, it
blinks on the display “1”.
