WARNINGS
Do not use the oven door handle to move the
appliance, for example to remove it from the
packaging.
The appliance is in class 1 or class 2
subclass 1.
OVERALL DIMENSIONS
895
600
755
815
h*
h* = 115 / 165
min.100 mm
min. 50 mm
min. 650 mm
min. 400 mm
"0" mm "0" mm
min. 50 mm
The cookers are fitted with 4 legs for easy
adjustment of height to suit adjacent furniture
(Fig. 8 / 8A).
GB
1000
600
960 900
mod. EKM 90460 X mod. EKM 90460 X
mod. EKM 10 460 X
Mod. EKM 10460 X (fig. 8A).
Fig.
8
To assemble legs, lift the cooker up and screw the
four legs into the suitable threadings located at the
corners on the underside of the appliance (fig 8).
Mod. EKM 90460 X (fig. 8).
Fig. 8A
IMPORTANT:
Any adjacent furniture must be able to
withstand high temperatures (min. 90°C).
If the appliance is to be installed near units,
leave the minimum gaps specified in
figure 7B .
Fig.
7B
INSTRUCTIONS FOR THE USER
14
REG. MAX 15mm
The cooker must not be placed on a pedestal
