Installation Instructions
1. Remove door tape and empty drum con-
tents, including foam shipping brace inside
rubber gasket of door.
2. Using a foam corner post from the packag-
ing to protect the floor, carefully lay the
washer on its back.
x 2
CAUTION
EXCESSIVE WEIGHT HAZARD
To avoid back or other injury, have more than
one person move or lift the washer.
IMPORTANT
Save styrofoam base and shipping braces
for use to help prevent washer damage dur-
ing any future moves.
3. Remove styrofoam base and set it aside.
4. Carefully return the washer to an upright
position.
5. Carefully move the washer to within 4 feet
(1 m) of its final location.
The drain hose is secured in place with two
plastic latching clamps. Press the locking tab
and release the drain hose.
Releasing drain hose
x3
x2
x3
Plastic
Clamp
Shipping
Spacer
Shipping
Bolt
Removing shipping hardware
Remove all of the following from the back of
the washer:
• 3 shipping bolts
• 2 plastic clamps
• 3 shipping spacers
NOTE
Rubber expansion material on spacers may
need time to relax before they can be easily
pulled through shipping hole.
IMPORTANT
Save all shipping bolts and spacers for future
use. If the washer is to be transported at a
later date, the shipping hardware must be
reinstalled to help prevent shipping damage.
8
