Fitting a Decor Panel on the Door
The door of this machine has frames for fitting plastic
laminate decor panel in the colour required to match
the dishwasher with the rest of the kitchen furniture. If
you want to do this you must provide this panel your-
self.
Width: 436 mm
Height: 592 mm
Max thickness: 4mm
To Fit the Panel
= Take the door frame off after removing the retaining
screws around the edge.
= Position the panel, refit the frame and tighten the
retaining screws around the edge.
Note
The panel should be fitted before positioning the
machine.
DOL 4
Water Supply Connections
The appliance may be fed with either hot (max. 60°C)
or cold water.
Nevertheless we advise you a cold water supply.
A hot water supply is not always efficient with very
soiled crockery as it shortens the washing
programmes a lot.
Feeding the appliance with a hot water supply (max.
60°C) will allow you to obtain considerably shorter
programmes.
As to the making of the connection itself, the coupling
nut fitted to the machine's supply hose is designed to
screw onto either a 3/4 inch gas thread spout, or toa
purpose made quick-coupling tap such as the Press-
Block.
To make this easier, the hose itself may be turned to
the left or the right. In either case, be sure to incor-
porate the strainer A supplied with the machine onto
the joint. See picture.
The water pressure must be within the limits given in
the technical specifications, as it will not function
correctly if pressure is outside these specifications.
Caution: the retaining ring must be correctly fitted to
avoid water leaks.
Avoid bends or kinks in the hose which could prevent
or slow down the flow of water.
If the machine is connected to new pipes or pipes
which have not been used for a long time, you are
advised to run the water for a few minutes before
connecting the inlet hose. This will prevent deposits
of sand or rust clogging the inlet hose filter.
