Electrolux EWM09312 - Comprehensive Alarm Summary Table

Technical Support - A.D.L. 15/70 599 74 23-12 Rev.00
4.5 Alarm Summary Table
ALARM
CODE
Description Possible fault Machine status/action Reset
E11
Water fill difficulty during washing
• Tap closed.
• Water pressure too low.
• Drain pipe improperly positioned.
• Water fill solenoid valve faulty.
• Leaks from pressure switch water circuit.
• Pressure switch faulty.
• Faulty wiring.
• Main circuit board faulty.
Cycle is paused with door locked START/RESET
E13
Water leaks
• Drain pipe improperly positioned.
• Water pressure too low.
• Water fill solenoid valve faulty.
• Leaks/clogging of pressure switch water circuit.
• Pressure switch faulty.
Cycle is paused with door locked START/RESET
E21
Drain difficulty during washing
• Drain tube kinked/clogged/improperly positioned.
• Drain filter clogged/dirty.
• Faulty wiring.
• Pressure switch faulty.
• Drain pump rotor blocked.
• Drain pump faulty.
• Main circuit board faulty.
Cycle is paused (after 2 attempts)
START
ON/OFF
RESET
E23
Faulty Triac for drain pump
• Faulty wiring.
• Drain pump faulty.
• Main circuit board faulty.
Safety drain cycle - Cycle stops with door open. RESET
E24
Drain pump TRIAC "sensing"
circuit faulty.
• Main circuit board faulty.
Safety drain cycle - Cycle stops with door
unlocked
RESET
