Technical Support - A.D.L. 9/70 599 74 23-12 Rev.00
Position 3
Water fill to pre-wash
compartment
Purpose of the test: To check the correct operation of the pre-wash
compartment water route.
Components activated:
Door safety interlock
• Pre-wash solenoid
Working conditions:
Door closed
• Water level below anti-flooding level
• Maximum time 5 mins.
LCD display
Water level in the tub is displayed (mm)
Position 4
Water fill to conditioner
compartment
Purpose of the test: To check the correct operation of the conditioner
compartment water route.
Components activated:
Door safety interlock
• Pre-wash and wash solenoid valves
Working conditions:
Door closed.
• Water level below anti-flooding level
• Maximum time 5 mins.
LCD display
Water level in the tub is displayed (mm)
Position 5
No command
Purpose of the test: -------------
Components activated: -------------
Working conditions: -------------
LCD display
