Electrolux LHR3233CK - 3.5 Installation of more than one hob; 3.6 Connection cable

290
60 30
520
490
min. 55
270
40
min. 950
min.
12
min.
28
min.
12 mm
min.
20 mm
min.
28 mm
1 2
3
3.5 Installation of more than
one hob
40-50 mm
50 mm
55 mm
30 mm
min. 500 mm
490 mm
270 mm
2
0
+
2
0
+
3.6 Connection cable
• The hob is supplied with a connection
cable.
• To replace the damaged mains cable,
use the cable type: H05V2V2-F which
withstands a temperature of 90 °C or
higher. Contact an Authorised Service
Centre. The connection cable may
only be replaced by a qualified
electrician.
www.electrolux.com8
