Electrolux PLMV169DCE - Parts List

44
GLMV169DBD
GLMV169DQD
GLMV169DSD
PLMV169DCE
PARTS LIST
Note: The parts marked “ ” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY
*
*
Δ
Δ
ELECTRIC PARTS
1 FH-DZB015MRY0 High voltage rectifier assembly 1
2 RC-QZA234WRE0 High voltage capacitor 1
3 RMOTDA264WRZZ Turntable motor 1 AL
4 RMOTDA270WRZZ Stirrer motor 1 AQ
5 RTHM-A136WRZZ Thermal cut-out N.O. 60
o
C (Hood Fan) 1 AG
6 RTRN-B087MRE0 Power transformer 1 BF
7 RV-MZA324WRZZ Magnetron 1 BC
8 QSW-MA085WRE0
Pri. interlock and door sensing switches 2 AE
9 FFS-BA016/KIT Monitor switch (V-16G-2C25)/fuse assembly(20A 250V AC) 1 AF
10 FACCDB011MRE0 Power supply cord 1 AP
11 QSOCLB006MRE0 Oven lamp socket 3 AE
12 FMOTEA402WRK0 Hood fan motor 1 BE
13 RMOTEA433WRZZ Fan motor 1 AR
14 RLMPTA086WRZZ Oven lamp 3 AE
15 RTHM-A135WRZZ Thermal cut-out 145
o
C (Cavity) 1 AG
16 FDTCTA201WRK0 AH Sensor 1 AU
CABINET PARTS
17 LSTY-B021MRP0 Rear stay 1 AF
18 PDIF-B066MRF0 Hood exhaust louver [GLMV169DBD] 1 AT
18 PDIF-B067MRF0 Hood exhaust louver [GLMV169DSD] 1 AT
18 PDIF-B068MRF0 Hood exhaust louver [GLMV169DQD] 1 AT
18 FDIF-B021MRK0 Hood exhaust louver [PLMV169DCE] 1 AT
19 GDAI-B064MRP0A Right base plate 1 AM
20 PCUSUB045MRP0 Cabinet cushion 1 AA
21 GCABUB142MRP0 Outer case cabinet [GLMV169DBD/PLMV169DCE] 1 BA
21 GCABUB143MRP0 Outer case cabinet [GLMV169DSD] 1 BC
21 GCABUB144MRP0 Outer case cabinet [GLMV169DQD] 1 BC
22 TMAPCB101MRR0 Schematic diagram 1 AB
23 FANGKB009MRY0 Hood lamp glass assembly [GLMV169DBD/PLMV169DCE] 1 AN
23 FANGKB029MRY0 Hood lamp glass assembly [GLMV169DSD] 1 AN
23 FANGKB013MRY0 Hood lamp glass assembly [GLMV169DQD] 1 AN
24 LANGQB016MRP0 Hood lamp glass angle [GLMV169DBD/PLMV169DCE] 1 AG
24 LANGQB082MRP0 Hood lamp glass angle [GLMV169DSD] 1 AG
24 LANGQB049MRP0 Hood lamp glass angle [GLMV169DQD] 1 AG
25 PGLSPB004MRE0 Hood lamp glass 1 AH
26 PCOVPB094MRT0B Base cover [GLMV169DBD/PLMV169DCE] 1 AY
26 PCOVPB095MRT0B Base cover [GLMV169DSD] 1 AY
26 PCOVPB090MRT0C Base cover [GLMV169DQD] 1 AY
27 PCUSUB040MRP0 Base cover cushion 1 AY
28 PCUSGB028MRP0 Cushion 1 AY
29 PCUSUB047MRP0 Mag cushion 1
CONTROL PANEL PARTS
30 CPWBFB099MRU0 Control unit 1 BL
31 HPNLCB204MRR0 Control panel sub. assembly [GLMV169DBD] 1 AZ
31 HPNLCB196MRR0 Control panel sub, assembly [GLMV169DQD] 1 AZ
31 HPNLCB195MRR0 Control panel sub, assembly [GLMV169DSD] 1
31 FPNLCB499MRK0 Control panel sub. assembly [PLMV169DCE] 1 AZ
32 FUNTKB415/KIT Key unit [GLMV169DBD/PLMV169DCE] 1 AX
32 FUNTKB417/KIT Key unit [GLMV169DQD] 1 AX
32 FUNTKB416/KIT Key unit [GLMV169DSD] 1
33 LANGQB061MRP0 Key fixing plate 1 AK
34 XEPSD30P10XS0 Screw; 3mm x 10mm 1 AB
35 XEPSD30P08XS0 Screw; 3mm x 10mm 3 AB
OVEN PARTS
36 FFTA-B005MRK0 Exhaust damper assembly 1 AH
37 FROLPB025MRK0 Turntable support assembly 1 AN
38 NTNT-A090WRE0 Turntable tray 1 AN
39 LANGKB010MRP0 Capacitor holder 1 BB
40 FCOVPB016MRK0 Stirrer cover assembly 1 AN
41 FFAN-B010MRK0 Stirrer fan assembly 1 AH
