61
Water
Ice Storage Bin
Water
Ice Storage Bin
C
o
n
t
r
o
l
A
r
m
Ejector
1. Holding Switch in normally open
position.
2. Heater remains energized.
3. Control Arm is rising.
Harvest Cycle
Water
Ice Storage Bin
Water
Ice Storage Bin
C
o
n
t
r
o
l
A
r
m
Ejector
1. Ejector reaches ice.
2. Motor stalls until ice loosens.
3. Heater remains energized.
Harvest Cycle
Step 3
Step 4
Step 5
Step 6
1. Completing 1st revolution of
Ejector .
2. Water Fill Switch closes, but
heater remains on, preventing
water fill.
Harvest Cycle
Ice Storage Bin
C
o
n
t
r
o
l
A
r
m
Ice Storage Bin
Ejector
Ice
1. End of 1st revolution.
2. Hold Switch opens.
3. Since Thermostat is still closed,
2nd revolution of Ejector begins.
Harvest Cycle
Ice Storage BinIce Storage Bin
C
o
n
t
r
o
l
A
r
m
Ejector
Ice
