Electrolux Side by Side Refrigerators - Water Fill System Testing

77
Figure H6
Ice Dispenser
Water Tank
Icemaker
Straight Connector
Adhesive Clip
attaches to the bottom of unit
Cover
attached to liner
Figure H7
Ice Dispenser
Water Tank
Water Filter
rear
Icemaker
Straight Connector
Elbow Connectors
Housing
Filter
O’ring (cup)
Cup
Cover
attached to liner
Adhesive Clip
attaches to the bottom of unit
Rear Filter System
No Filter System
