Group 5 - Setting control of temperature, drum and buzzer
Adjustable parameters
Factory
setting
Para-
meter /
group
Comments
5 01 Temperature °C / °F 0 - 1 0 / 1 0 / 1 0 = °C / 1 = °F
5 02 Temperature hysteresis 01 – 10 °K 1 2 Hysteresis in °K
5 03 Rotation clockwise 01 – 99 minutes 1 5 Only if reversing is ON
5 04 Pause between reversing 01 – 99 seconds 1 3 Only if reversing is ON
5 05 Reversing 01 – 99 minutes 1 5 minutes
5 06 Anticrease 00-01 0/1 1 0 = OFF / 1 = ON
5 07 Beep on key press 00-01 0/1 1 0 = OFF / 1 = ON
5 08 Beep at cycle end 0 – 60 seconds 1 10
5 09 Cooling, time, High temp. 1-20 min 1 3 Non-coin operated machines
1 1 Coin operated machines
5 10 Cooling, time, Med. temp. 1-20 min 1 3 Non-coin operated machines
1 1 Coin operated machines
5 11 Cooling, time, Low temp. 1-20 min 1 3 Non-coin operated machines
1 1 Coin operated machines
5 12 Option 1 1-20 min
5 13 Cooling, temp. (High) 30-85°C / 85-185°F 1 45 / 115 (45°C / 115°F)
5 14 Cooling, temp. (Medium) 30-85°C / 85-185°F 1 45 / 115 (45°C / 115°F)
5 15 Cooling, temp. (Low) 30-85°C / 85-185°F 1 45 / 115 (45°C / 115°F)
5 16 Option 2 30 - 85°C
5 17 Temperature hysteresis (outlet) 01 – 10 °K 1 1 Temperature hysteresis for damper
Finishing cabinet only
5 18 Temperature offset (outlet) 0 - 85°C 1 5 Temperature offset for damper
Finishing cabinet only
5 19 Power CTRL 0 - 1 1 0 / 1 0 = OFF / 1 = ON
5 20 Condense pump running time 01 - 255 seconds 1 15 4130C only
Steam injection time 01 - 255 seconds 1 60 Finishing cabinet only
* 5 04 T4900/T41200 12 seconds
** 5 05 Dryers with reversing
and 1 motor (T4190 1-phase) 15 seconds
Designation Range Step
First 2 digits
Last 2 digits
=
+
140°C
Example
Warning!
Incorrect parameter setting can
damage the dryer.
