Electrolux TD75 - Group 6 - Setting Maximum Values

27
Program
Group 6 - Setting maximum values
Adjustable parameters
Factory
setting
Para-
meter /
group
Comments
6 01 Number of P programmes 1 – 9 1 0 Coin
2 AHL AutoStop
3 AHL RMC
5 OPL AutoStop
9 OPL RMC
6 02 Inlet temperature 4300/30x30 Gas 80 - 180°C / 176 - 356°F 1 180°C / 356°F
4250/4350 Gas 80 - 155°C / 176 - 310°F 155°C / 310°F
El 80 - 155°C / 176 - 310°F 155°C / 310°F
4190 El 80 - 180°C / 176 - 356°F 180°C / 356°F
4130 El/condens 0
Clean Room Steam 180°C / 356°F
Clean Room El 160°C / 320°F
ALL Steam - 0
Designation
Range
Step
Factory
setting
Para-
meter /
group
Designation
Dryer/heating type Range Step
Factory
setting
Para-
meter /
group
Comments
6 03 Max. time on time control 10 – 90 min 1 90 Max. time which can be selected (also coin)
6 04 Max. time on P programs 30 – 90 min 1 90 Max. time on AutoStop or RMC
6 05 Autostop temperature 30 - 70°C / 65°C / Depending of the dryer type
86 - 160°F 149°F
6 06 Error code E18 0 / 1 1 0 0 = activated / 1 = deactivated
6 07 Error code E08 flashes when the
loading door is open 0 / 1 1 0 0 = activated / 1 = deactivated
6 08 Vaccum error timer 0 - 15 sec. 1 13 Time to pass before vacuum signal appears
6 09 Ecopower Enable temperature 0 - 100°C 1 55°C / Enable temperature for starting Ecopower.
*40 - 50°C / 131°F This temperature is used for adjustment for
32 - 212°F small loads
*104 - 122°F
6 10 Ecopower Extra time 0 - 90 min 1 10 min Extra time before Ecopower enable,
*5 - 15 min time to run after Autostop temperature is
fulfilled
6 11 Ecopower Temperature 0 - 99°C 1 55°C / Temperature to regulate the heat (on/off)
*40 - 50°C / 113°F after the Ecopower extra time is fulfilled
32 - 210°F
*104 - 122°F
6 12 Ecopower Start up time 0 - 99 min 1 1 min Time before starting Ecopower function after
*1 - 15 min program start
Designation Range
Step
* Recommended range. Values set out of range may deteriorate the performance of the machine.
