The power supply cable must be accessible after installing the machine.
Connect the machine to an earthed socket, in accordance with current wiring regu-
lations.
Changing door stop
The door stop may only be changed by a specialist. If necessary, please contact
our after-sales service or your specialist dealer.
Before changing the door stop, disconnect the mains plug.
AC
C
D
A
B
1. Open loading door.
2.
Unscrew hinge A from the front of the machine and take off the loading door.
3.
Remove cover plates B and C. To do this, insert a thin screwdriver into the slots
as shown in the illustration, press downwards slightly and pry out the cover
plates.
34 electrolux installation
