Product description
10
2
6
8
11
4
1
3
7
9
5
1 Control panel
2 Drawer with condensed water container
3 Fine strainer (lint filter)
4 Large mesh filter (lint filter)
5 Micro-fine filter (lint filter)
6 Rating plate
7 Loading door (reversible)
8 Base door upstream of heat exchanger
9 Button for opening door in plinth
10 Air slots
11 Screwed feet (with height adjustment)
8 electrolux product description
