 Unlock the pin by pulling it out approximately 2 cm.
 Lower the ram to facilitate withdrawal of the assembly.
 Completely remove the pin.
 The hopper-cover and cover-ram assembly can be wi-
thdrawn.
- Wash the equipment in hot water, rinse and dry.
- Clean the body with a clean, damp sponge.
• The cutting chamber, hopper and lever-ram can be washed
in a dish-washer.
4.1 BETWEEN TWO SESSIONS
- Remove the cutting equipment (plate, grid and ejector) and
the pusher.
- Remove the cutting chamber.
- Remove the hopper-cover and the lever-ram, following the
instructions below:
 Raise the ram up to the clipped position.
(This is the only position in which the pin can be locked/un-
locked).
4.3 STORAGE
- After cleaning, put all the cutting equipment away carefully in
the storage case fi xed to the wall.
-
Clean the outside of the vegetable slicer with a damp sponge
and a mild detergent and then rinse using a clean sponge.
Note:
- Do not use abrasive detergents as these scratch the surfaces,
or bleach-based detergents as these tarnish the aluminium.
4.2 AFTER USE
- Refer to § 4.1.
- Clean the removable elements in hot water with the addition
of detergent-degreaser-disinfectant which is compatible with
the materials.
- Rinse with clean water and leave to dry.
Recommendation: for MT grids, push any trapped cubes using
a carrot. Metal instruments are not to be used.
4.2
4.1
4.3
Cleaning, hygiene and storage
ATTENTION!!
Before dismantling any part, disconnect the appliance from the power supply.
Before using any cleaning product, be sure to read the instruction and safety instructions accompanying the product and use
appropriate protective equipment.
Do not wash the machine using a pressure washer, a spray or by immersion
Take care when handling screens and plates. (Risk of CUTS – ELECTRIC SHOCK).
- With the other hand, hold the plate on the outside and using the
fi nger grips turn sharply in an anti-clockwise direction .
- Raise it using a to-and-fro rotation movement.
5.3 JAMMED PLATE:
- Unplug the appliance.
- Place one hand fl at on the ejector and stop it rotating.
5.3a
5.3b
Fault-fi nding
5.1 IF THE APPLIANCE WILL NOT START, CHECK THAT:
• The machine is plugged in.
• The electrical power supply to the socket is correct.
• The hopper is properly locked.
• The lever-ram is down.
• The pin is locked.
5.2 ABNORMAL NOISE:
• Stop the appliance.
• Check that the plate, grid and ejector are properly in place.
• Remove, clean if necessary and refi t.
• If the noise persists and the appliance lacks power, check
that:
- The three-phase motor is not running on 2 phases.
- The drive belt is not worn or needs tightening (see § 6.1).
5
TR2S GB 10 06
