Hand tighten bearing
and nut onto shaft
(Note top race ts into recess)
Install the bearing open
side up. Apply IKV-Fluor
grease
Place the top race (larger
hole) groove down
Markings may be dierent
than shown!
Tighten nut until rm
Place the lower race (groove
up) in the cup and apply a
small amount of grease
The upper bearing race has a
larger hole.
Test t the upper race rst
15 mm
15.5 mm
!
Upper
Lower
Tango Turntable Service
Repack and Install bearing
Upper race MUST recess
into turntable holder.
See next page for
proper bearing tension
setting
4
5
3
2
1
