22
User manual
12Technical Data
Dimension Width/ Height/ Depth/
Total depth
686 mm/ 1098 mm/ 765 mm
839 mm
Electrical connection Voltage
Overall power
Maximum current
Frequency
220-240 V
2200 W
10 A
50 Hz
Level of protection against ingress of solid particles and moisture ensured by the protective
cover, except where the low voltage equipment has no protection against moisture
IPX4
Water supply pressure Minimum
Maximum
0,5 bar (0,05 MPa)
8 bar (0,8 MPa)
Water supply Cold water
Hot water
Maximum Load Cotton 12 kg
Energy Efficiency Class A+
Spin Speed Maximum 1050 rpm
1. The appliance works correctly if the water pressure is not less than 0.05 MPa (0.5 bar). If you cannot connect the
water inlet hose to the cold water tap of the primary hydraulic system, connect it to your domestic cold water stor-
age system.
2. Connect the water inlet hose to a water tap with a 3/4'' thread.
3. Make sure that the hot water temperature of your domestic system is not more than 55 ℃.
