Page 18
2.3.3 Pressure Switch
Voltage : 220/240 V
Frequency : 50/60 Hz (16 A – 3
Pins)
2.3.4 Diverter
Voltage : 220/240 Volt
Frequency : 50/60 Hz
Power : 8 W
Resistance : 6840 ±5 
2.4 Detergent Dispenser
2.4.1 Detergent Compartment:
Main wash compartment : 40cm³ (25/15)
Prewash compartment : 5cm³
2.4.2
Detergent Dispenser Bobbin:
Voltage 220/240 Volt
Frequency : 50/60 Hz
Resistance : 4450 ±10 
2.4.3 Rinse Aid Compartment:
Aid rinse cap : 150cm³
Factory outlet setting position : Level 3
2.4.4 Dispenser Rinse Aid Sensor:
Voltage : 250 V
Switched Current : 16 (4) A
Current through closed contact: 2.5 max.
2.5 Hose Inlet Valve Safety
Voltage : 220/240 Volt
Frequency : 50-60 Hz
Total Power : 8W
Flowrate : 3.5 lt/min
Resistance : 1960 ± 196  (20ºC)
Single inlet and single outlet standard single coil solenoid
valve. Assembled to the basement and connect to the air
break by hose.
