CHAPTER ONE: OVERVIEW
1.1: Specifications
Power Input
AC: 15Vac, 30VA transformer.
Battery backup: 12Vdc, 6.5 Ah or 7Ah (UL requirement).
Power Output
Auxiliary power - regulated 12Vdc nominal at 1A max. including keypads and detection
devices for 4 hours standby. (For CSFM Fire applications - 220mA max. including
keypads and smoke detectors for 24 hours standby).
Bell output - regulated 12Vdc nominal from auxiliary power, unregulated 9 – 18 Vdc,
600mA total auxiliary power.
Zones
Number of zones - 8 onboard (expandable to 32)
Keypads
Types - 3108 LCD keypad, 3106 LED keypad
Number of keypads - Up to 8 supervised
Current draw - 40mA without backlight, 60mA with backlight
Distress Keys - 3 user initiated
User Codes
Number of users – 15
Number of digits per user code - 3 to 6
Authorization levels - 15
Open/Close
Windows
Number of windows - 1 opening window + 1 closing window for
each day of the week per sub-system
Window sizes - + 15 min, + 30 min, + 45 min, +60 min.
Remote
Programming
Equipment - Remote Programmer software package.
Access - Direct (Password), Callback, Off-hook.
Current
Consumption
Control Panel: Approximately 130mA
3108 LCD Keypad: 20mA without backlight, 60mA with backlight.
3106 LED Keypad: 20mA without backlight, 70mA with backlight.
3508 Zone Expander Module:
10mA
3528 Wireless Zone Expander Module:
10mA
3402 Output Relay Module:
15mA all relays deactivated, 30mA per activated relay.
3407 Output Relay Module:
15mA all relays deactivated, 30mA per activated relay.
3417 Transistor Module:
10 mA all transistors deactivated.
725mA all relays transistors (drawing a max. 100mA each).
Operating
Temperature
0° to 60°C (32° to 140°F).
Dimensions
12” x 12” x 4” (30.5cm x 30.5cm x 10.2 cm).
Weight
Approx. 6.5 lbs. (3 Kg).
