Elektro-Automatik PS 8000 DT Series User Manual

27
Instruction Manual
PS 8000 DT Series
EN
Date: 02-09-2012
About the device
PS 8160-04 DT PS 8080-40 DT PS 8360-10 DT PS 8080-60 DT PS 8360-15 DT
Mains input
Input voltage 90…264V AC 90…264V AC 90…264V AC 90…264V AC 90…264V AC
Input voltage with derating - - - 90...150V 90...150V
Input current at 230V max. 3.2A max. 4.8A max. 7.5A max. 7.5A max. 7.5A
Input current at 100V max. 7.5A max. 11.4A max. 11.4A max. 11.4A max. 11.4A
Input frequency 45…65Hz 45…65Hz 45…65Hz 45…65Hz 45…65Hz
Input fuse T 8A T 16A T 16A T 16A T 16A
Power factor > 0.99 > 0.99 > 0.99 > 0.99 > 0.99
Output - Voltage
Nominal voltage U
Nom
160V 80V 360V 80V 360V
Adjustable range
0V…U
Nom
0V…U
Nom
0V…U
Nom
0V…U
Nom
0V…U
Nom
Stability at mains fluctuation ±10% ∆U
IN
< 0.02% < 0.02% < 0.02% < 0.02% < 0.02%
Stability at 10…90% load < 0.05% < 0.05% < 0.05% < 0.05% < 0.05%
Ripple LF BWL 20MHz < 20mV RMS < 4mV RMS < 11mV RMS < 4mV RMS < 8mV RMS
Ripple HF BWL 20MHz < 120mV P-P < 10mV P-P < 30mV P-P < 10mV P-P < 50mV P-P
Accuracy* ≤ 0.2% ≤ 0.2% ≤ 0.2% ≤ 0.2% ≤ 0.2%
Resolution of display 100mV 10mV 100mV 10mV 100mV
Remote sense compensation max. 2V max. 2,5V max. 8V max. 2,5V max. 8V
Overvoltage protection
threshold (adjustable)
0…176V 0….88V 0…396V 0….88V 0…396V
Output - Current
Nominal current I
Nom
4A 40A 10A 60A 15A
Adjustable range
0A…I
Nom
0A…I
Nom
0A…I
Nom
0A…I
Nom
0A…I
Nom
Stability at mains fluctuation ±10% ∆U
IN
< 0.05% < 0.05% < 0.05% < 0.05% < 0.05%
Stability at 0…100% ∆U
OUT
< 0.15% < 0.15% < 0.15% < 0.15% < 0.15%
Ripple LF BWL 20MHz < 1mA RMS < 7mA RMS < 0.45mA RMS < 7mA RMS < 0.45mA RMS
Ripple HF BWL 20MHz < 3mA P-P < 19mA P-P < 1mA P-P < 19mA P-P < 1mA P-P
Accuracy* ≤ 0.2% ≤ 0.2% ≤ 0.2% ≤ 0.2% ≤ 0.2%
Resolution of display 1mA 10mA 10mA 10mA 10mA
Transient recovery time 10….90% load < 2ms < 2ms < 2ms < 2ms < 2ms
Output - Power
Nominal power P
Nom
640W 1000W 1000W 1500W 1500W
Nominal power at derating - - - 1000W 1000W
Adjustable range -
0...P
Nom
0...P
Nom
0...P
Nom
0...P
Nom
Accuracy* - ≤ 1% ≤ 1% ≤ 1% ≤ 1%
Resolution of adjustment - 1W 1W 1W 1W
Efficiency ≤ 92% ≤ 93% ≤ 92% ≤ 93% ≤ 93%
Miscellaneous
Cooling by fan by fan by fan by fan by fan
Ambient temperature 0….50°C 0….50°C 0….50°C 0….50°C 0….50°C
Storage temperature -20….70°C -20….70°C -20….70°C -20….70°C -20….70°C
Humidity rel. < 80% < 80% < 80% < 80% < 80%
Dimensions (WxHxD) 330x118x308mm 330x118x388mm 330x118x388mm 330x118x388mm 330x118x388mm
Weight 6,5kg 8,5kg 8,5kg 8,5kg 8,5kg
Sharebus for parallel connection no yes yes yes yes
Article number 09200135 09200136 09200138 09200137 09200139
Series connection
Parallel connection
Humidity
Isolation
Safety
EMC standards
Overvoltage class
Protection class
Analogue programming
Voltage range
Accuracy set/actual values
Input impedance
≤
0.2%
approx. 53kΩ
0…5V or 0…10V (selectable)
<80%
Input to output: 2500V, Output to enclosure: 500V
possible, up to max. 600V total voltage
possible, max. 30 units, models from 1000W via Share bus
Class I
EN 60950
EN 61326, EN 55022 Class B
Class II
* Related to the nominal value, the accuracy denes the maximum allowed deviation between set value and actual value.
Example: a 65V model has min. 0.2% voltage accuracy. This is 130mV. When setting a voltage of 5V and with an allowed maximum deviation of 130mV, the resulting
actual value could be between 4.87V and 5.13V.
