Revised March 30, 2005 Versa DRIVE C1
Page 10 of 11 DRAFT COPY User Manual
6. Specifications
Part Number VD-C1
Width 1/2 standard rack unit (19.0” / 430mm)
Height 1U (1.75” / 44.4mm)
Depth 12” (304.8mm)
Weight 160.2 oz 10.0125 lbs = 4.542 kg
Construction Powder Coated Steel
Mounting Stand alone with plastic feet or rack mounted with included rack ears
Environmental IP30 (indoor use only)
Cooling Passive
Storage Temperature -40°C to 70°C
Operating Temperature 0°C to 50°C
Operating Humidity 10% to 85%, non condensing
Front Panel Power Switch
LED Display
3 control buttons - Mode, Up, Down
Compact Flash Slot
Rear Panel AC Power: 100-240 VAC 50/60Hz (female IEC connector)
Serial Data output for Versa fixtures (female XLR, 6-pin)
Local Data output for Versa fixtures (female XLR, 4-pin)
DMX input (male XLR, 5-pin)
DMX ouput (female XLR, 5-pin)
Contact Closure (female DB-9)
Output Data 1,024 pixel output on Serial Data and Local Data ports simultaneously
Data Output Rate 30 FPS (frames per second) maximum output rate
WARNING Severe risk of electric shock. No user-serviceable parts inside.
Information and specifications in this document are subject to change without notice.
Element Labs, Inc. assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual.
