Element (ELCHW321) 32 inch LCD Television Service Manual
Proprietary & Confidential Page 16
6. Keyboard Replacement
• Remove Back Cover.
• Disconnect Keyboard cable.
• Remove 2 outer screws and carefully lift the Keyboard from the unit.
(Figure 16)
• Remove the 2 inner screws and lift the cover from the Keyboard. Use extreme care when
releasing the tabs along the edge of the cover, as the tabs are very delicate.
(Figure 17)
• To reinstall the Keyboard, place the cover over the Keyboard and secure the 2 inner screws.
Place the Keyboard in slot and secure the 2 outer screws then reconnect the cable.
