APPENDIX THREE
Step 16: On the gas valve, between the Manual Knob and the
Main Valve Knob is a black plastic cap which hides access to the
pressure regulator adjustment screw. Remove black plastic cap
to gain access to the pressure regulator adjustment screw. See
Figure 5.
Step 17: Connect LP gas supply to replace. Loosen the
screw inside the manifold pressure test port and connect the
manometer to the port. See Figure 6.
Step 18: Turn on the replace and set the ames to high. While
turning the pressure regulator screw, adjust the manifold
pressure to the setting in the installation manual.
Step 19: Turn o the replace, remove the manometer and
close the test port screw.
Step 20: Replace the hearth panel, the burner media and the
glass panel. Check for proper replace operation.
Pilot
Inlet
Nut
Figure 4.
Step 10: Tighten the orice locknuts.
Step 11: Remove the pilot burner inlet tube (10 mm) from the
pilot burner. See Figure 4.
CAUTION: The next step involves small parts which can be
easily lost.
Note: The pilot inlet nut is easily reached at the bottom of
the replace when the replace is tilted slightly rearward.
Take care to stabilize the replace!
Step 12: Using a 10mm wrench, loosen the pilot inlet nut and
remove the pilot burner inlet tube from the pilot burner. The
pilot orice should drop out of the pilot burner. See Figure 4.
Step 13: Remove the pilot burner orice and replace it with
the LP orice (stamped 27) provided. Take care to observe the
proper orientation. See Figure 4.
Step 14: Connect the pilot burner inlet tube and tighten the
inlet nut.
Step 15: Insert the burner into the rebox and securely fasten
with the bolts removed earlier.
Pressure
Regulator
Adjustment Screw
(cap removed)
Figure 5.
Figure 6.
Manifold Pressure Test Port
Pilot
Inlet
Tube
Pilot
Orice
Pilot
Burner
