11
The table 3.
W
100
Primary
Converter
Designation
conditional a
designation НСХ
Range of measured
quantities
1 2 3 4
«Cu85» 50М 1,4280
-50÷200 °С
«Cu65» 50М 1,4260
-50÷200 °С
«Cu83» 53М 1,4280
-50÷200 °С
«Cu63» 53М 1,4260
-50÷200 °С
«Cu81» 100М 1,4280
-50÷200 °С
«Cu61» 100М 1,4260
-50÷200 °С
«PtH5» 50П 1,3910
-50÷600 °С
«PtH1» 100П 1,3910
-50÷600 °С
«Ptb1» Pt100 1,3850
-50÷600 °С
«HA» ХА(К) -
-50÷1300 °С
«НЕ» ХК(L) -
-50÷600 °С
«ПП» ПП(S) -
-50÷1700 °С
«8P» ВР(А)-1 -
-50÷2500 °С
«t05» - -
0÷5 мА
«t020» - -
0÷20 мА
«t420» - -
4÷20 мА
«U100» - -
0÷100 мV
«U075» - -
0÷75 мV
«rr» - -
0÷320 Ohm
10) "dP1.n" - minimum significance of the range of indication.
There is minimum significance of the range of transformation (significance of indications
appropriate to maximum significance of the input source range) for input source signals in the form
of a force or a direct current voltage
Factory installation - «0.0».
11) "dP2.n" - maximum significance of the range of indication.
For source signals in form of forces or a direct current voltage maximum significance of a
range of transformation (significance of indications appropriate to minimum significance of the
input source range).
Factory installation - «100.0».
12) «Sqr.n» - function of a square root extraction.
«Sqr.n» = 0 - the induced significance at measurement of current or voltage is calculated
under the formula
Value = dP1 + (dP2 – dP1) x
)Im(Im
)Im(
inax
inI
−
−
, (5.1)
Where Value - significance, induced on the indicator;
I - measured significance of current or voltage;
Imin, Imax - limits of measurement of current or voltage;
dP2, dP1 - range of transformation according to article 4.2.9.3.11).
«Sqr.n» = 1 - the induced significance at measurement of current or voltage is calculated
under the formula
Value = dP1 + (dP2 – dP1) x
)Im(Im
)Im(
inax
inI
−
−
(5.2)
Factory installation - "Sqr.n" = 0.
