Identification of parts
27
How to Insert the Batteries
Remove the battery cover according to the arrow
direction.
Insert new batteries making sure that the (+) and ()
of battery are matched correctly.
Reattach the cover by sliding it back into position.
Note:
• Use 2 LR03 AAA(1.5volt) batteries. Do not use
rechargeable batteries. Replace batteries with
new ones of the same type when the display
becomes dim.
Storage and Tips for Using
the Remote Controller
The remote controller may be stored mounted on a
wall with a holder.
Note: The remote controller holder is an optional part.
How to Use
To operate the air conditioner, aim the remote con
troller at the remote controller receiver window. The
remote control will operate the air conditioner at a
distance of up to 7m when pointing at remote control
receiver window of the air conditioner.
Remote controller holder
signal receptor
